37mm Gearbox Reduction 24v 500 Electric Micro DC Motor

GB37-500TB is a micro DC speed reducer motor specially customized by Weishida for customers.37mm Gearbox Reduction 24v 500 Electric Micro DC Motor is a small, efficient and reliable motor, widely used in a variety of machines and equipment. It adopts advanced technology and technology, has high transmission efficiency and accurate operation control, can effectively reduce the operation speed of the machine and equipment, improve the output force and stability of the equipment.This motor has a long service life, low power consumption, low noise and small volume, which is very suitable for installation in a narrow space. It also has a variety of functions and options, and can customize different deceleration proportions and output axis types according to the user's needs. In industrial automation, intelligent home, robot and many other fields have a wide range of application prospects. Its high quality, high reliability performance, can effectively improve the production efficiency and quality of machinery and equipment, to create more value for users.

The reducer motor includes the motor part and the reducer part. The structure of the motor is mainly the stator, the rotor and the brake device. The stator is composed of ring magnet and coil, and the rotor is composed of iron core and winding. The brake device includes brake pad, brake, etc., and controls the running state of the motor by means of electric control signal. The reducer part includes gear sets, bearings and lubrication system. Gear according to different deceleration ratio and requirements, common inclined gear, cylindrical gear and planetary gear. Bearings have ball bearings and roller bearings, which can withstand large radial and axial forces. The lubrication system includes components such as the lubricating oil tank, lubrication pump and lubricant piping.

Product Description

The reduction ratio of the miniature deceleration motor determines the speed reduction of the output shaft. The size of the reduction ratio is achieved by rotating the gear ratio between the input and output axes of the reducer. For example, if the deceleration ratio is 1:10, then the speed of the output shaft will be 10 times slower than that of the input shaft, and the torque will be 10 times greater than that of the input shaft. This makes miniature deceleration motors an ideal device for small torque output but low speed.

The conventional encoder does dual channels by default, which can calculate the speed and rotation direction. If there is no need to detect the rotation direction, save the cost, you can be customized to do a single channel.

Two channels/Single channel Hall Encoder

Size and resolution can be customized

Consumption current digital output

High reflection frequency from 0KHz to 100KHz

Temperature range:-40℃-+125℃

The code disk of the photoelectric encoder can be customized, that is, the higher the resolution, the higher the processing difficulty, and the higher the product cost. The processing technique determines the height of the resolution.

Wide resolution range,standard 100CPR output.Also OK to customized from 96CPR to 1024CPR

Single 5V supply ,No signal adjustment requeired,Two channels quadrature output

TTL compatible

Count Frequency:100KHz max

Operation temperature:-40-+85℃

37mm Gearbox Reduction 24v 500 Electric Micro DC Motor have these following advantages:
1. Reversible use: the micro large torsional worm DC motor can change the rotation direction of the shaft by changing the positive and negative wiring.
2. Self-locking: self-locking worm gear deceleration motor is adopted, that is, when the motor is not energized, the output shaft is fixed and self-locking.
3. Big twist: DC gear motor is not easy to break tooth wear. Internal metal gear decelerates with greater torsion.
4. A useful motor: mainly used in ATM machines, vending machines, printers, photocopiers, video recorder, office automation equipment, etc.
5. Aluminum alloy: good aluminum alloy shell is corrosion resistant, not easy to rust, durable structure, low power consumption, low noise.
