Electric Carbon Brush DC Motor
shaft length: 8.0±0.15mm;
Axial clearance: 0.05-0.5mm ;
Length: 43mm,
Electric carbon brush dc motor widely used in medical beauty, maternal and child health care, smart home, vehicle, office, model aircraft and other fields. We have many years of experience in micro-motor production and research and development to escort your products and provide customers with flexible and professional customized services.
Description
Overview
Warranty | 3 months - 1 year |
Place of Origin | Guangdong, China |
Brand Name | Vshida |
Model Number | VRK-3050SA |
Usage | Household appliances, cars, electric bicycles, printers, copiers, fans, remote control models, air pumps, water pumps, office automation equipment, ATMs, vending machines, vacuum cleaners, infinite power tools, medical equipment, car massage seats, etc. |
Type | Brushed dc motor |
Weight | TBD (different ratio different weight) |
Components | Diversifed |
Construction | Permanent Magnet |
Commutation | Brush |
Protect Feature | Customized |
Efficiency | 92% |
Rated power | 2.3 (W) |
No-lead speed | 5724 (rpm) |
Rated Voltage | 6.0 V/12.0 V |
Max Current | 0.666 (A) / 0.309 (A) |
Starting torque | 34.823mNm / 58.375mNm |
| Dimensions | 42.6*10(mm) |
Payment terms | 30% advance, 70% balance |
Certificate | IATF 16849 |
Customizated | Acceped |
Company Highlights
Supply Ability
Supply Ability: 4500000 Piece/Pieces per Month dc motor with counterweight
Packaging & Delivery
Packaging Details
Micro motor packing: Carton Box Our standard shipping mark for each model is as below Q'ty: pcs N.W.: kgs G.W.: kgs Meas.: L*H*W cm Your own shipping instruction is welcome.
Port: Shenzhen / HongKong
Product Description
An average of two months to develop a new motor
Product Parameter
VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STARTING | ||||||
OPPERATING RANGE | NOMINAL V | SPEED r/min | CURRENT A | SPEED r/min | CURRENT A | TORQUE mN.m | OUTPUT W | TORQUE mN.m | CURRENT A |
3.0-8.0 | 6 | 5724 | 0.125 | 4820 | 0.666 | 5.502 | 2.777 | 34.823 | 3.551 |
8.0-15 | 12 | 3972 | 0.045 | 3468 | 0.309 | 7.412 | 2.691 | 58.375 | 2.128 |
Product Size
Performance Curve
The above specifications are for reference only, the type and parameters of the specific Electric carbon brush dc motor can be customized
Product Features
Electric carbon brush dc motor are used in household appliances, water pumps, air pumps, commercial equipment and other fields, with long service life, stable performance, low speed and high torque, high efficiency, good mute effect, customized technical data
Product Details
| 100% actual photos |
|
Rotor: pure copper wire winding, high-quality iron core, reduce energy loss and reduce current resistance | End cap: use high-quality carbon brushes/electric brushes to increase the service life and make the matching degree higher | |
| 100% actual photos |
|
Bearings: choose brand bearings to reduce motor noise and increase service life (bearings can be customized) | Chassis: selected high-quality materials with high hardness, high temperature resistance, corrosion resistance, wear resistance and rust resistance, with a longer service life |
Company Strength
Product Certificate
Some of our partners
Our Advantage
1. Provide customized design for customers.
2. Product name: 3035SA carbon brush DC motor; rated voltage: DC 12V/6V; rated speed: 3400±10% (rpm).
3. Output shaft length: 8.0±0.15mm, starting voltage: ≤3.0v, axial clearance: 0.05-0.5mm.
4. Has its own design and development team, and develops a new motor in an average of two months.
5. Perfect after-sales service system and professional international service team to ensure worry-free after-sales.
Application
Transport Packing
If you have special packing needs, please contact us in advance.
Buying Guides
Payment & Delivery
FAQ
1. Can it be customized for customers?
Yes, we can customize according to your needs, we have R&D department, our technicians can design dimension drawings according to your requirements.
2. Do you have after-sales service?
Yes, a good after-sales service system, dealing with customer complaints and solving problems for customers.
3. Can you manufacture motors according to our requirements?
Yes, we have a professional team that can do anything you want.
4. How is your quality guaranteed?
We have 100% quality assurance to our customers. We will be responsible for any quality problems.
5. Can we visit your factory before placing an order?
Yes, you are very welcome to have a good relationship for the business. If possible, contact us before your departure and we will provide you with the route and arrange a time to pick you up.
