Coreless brushless motors suitable for home appliances
VSD's coreless brushless motors use the latest motor manufacturing technology, with excellent high-efficiency performance, quieter operation, faster response, and high-precision control. This series of motors supports multiple rated voltage options of 6V, 12V, 24V and 36V, with diverse designs, including output models such as built-in drives and Hall sensors, to meet a variety of application requirements.
Description
New Coreless Brushless Motor
| Product image |
|
|
|||||||||||||||||
| Motor model | VEC-16 series | VEC-19 series | |||||||||||||||||
| MOTOR | TYPE | EC1636 | EC1644 | EC1656 | EC1930 | EC1935 | EC1946 | ||||||||||||
| LENGTH"L" MM |
36mm | 44mm | 56mm | 30mm | 35mm | 46mm | |||||||||||||
| VOLTAGE | OPERATING RANGE |
10~14 | 22~26 | 32~38 | 22~26 | 28~32 | 32~38 | 22~26 | 28~32 | 32~38 | 5~7 | 10~16 | 22~26 | 5~7 | 10~16 | 22~26 | 5~7 | 10~14 | 22~26 |
| NOMINAL V |
12 | 24 | 36 | 24 | 30 | 36 | 24 | 30 | 36 | 6 | 12 | 24 | 6 | 12 | 24 | 6 | 12 | 24 | |
| OUTPUT | OUTPUT RATING W |
9.7 | 19 | 19 | 21.5 | 21.5 | 21.2 | 34.2 | 33.5 | 34 | 7.7 | 11.6 | 15.4 | 7 | 13.8 | 18.5 | 9.2 | 15.4 | 25.7 |
| RATED TORQUE m.Nm |
6 | 5 | 5 | 7.5 | 7.5 | 7.5 | 8.5 | 8.5 | 8.5 | 7.5 | 7.5 | 7.5 | 9 | 9 | 9 | 10 | 10 | 10 | |
| RATED SPEED rpm |
15800 | 37000 | 3700 | 28000 | 28000 | 27600 | 39200 | 38400 | 38900 | 10000 | 15000 | 20000 | 7600 | 15000 | 20000 | 9000 | 15000 | 25000 | |
| OUTPUT LEAD | Signal | Hall | Hall | Hall | Built-in driver | Hall | Hall | Built-in driver | Hall | Hall | Built-in driver | Hall | Hall | ||||||
| Product design |
|
|
|||||||||||||||||
| Product performance | - | - | |||||||||||||||||
| Product image |
|
|
|||||||||||||||||
| Motor model | VEC-20 series | VEC-22 series | |||||||||||||||||
| MOTOR | TYPE | EC2040 | EC2053 | EC2063 | EC2232 | EC2240 | EC2248 | ||||||||||||
| LENGTH"L" MM |
40mm | 53mm | 63mm | 32mm | 40mm | 48mm | |||||||||||||
| VOLTAGE | OPERATING RANGE |
22~26 | 28~32 | 32~38 | 16~20 | 22~26 | 32~38 | 10~14 | 22~26 | 32~38 | 10~14 | 22~26 | 28~32 | 10~16 | 22~26 | 32~38 | 10~14 | 22~26 | 32~38 |
| NOMINAL V |
24 | 30 | 36 | 18 | 24 | 36 | 12 | 24 | 36 | 12 | 24 | 30 | 12 | 24 | 36 | 12 | 24 | 36 | |
| OUTPUT | OUTPUT RATING W |
15.4 | 16.4 | 16.4 | 46.2 | 47.2 | 48.2 | 25 | 100 | 220 | 9.7 | 9.6 | 9.1 | 17.6 | 17.6 | 17.3 | 20.5 | 112 | 112 |
| RATED TORQUE m.Nm |
6.3 | 6.3 | 6.3 | 10 | 10 | 10 | 16 | 50 | 70 | 6 | 6 | 6 | 12 | 12 | 12 | 8 | 20 | 20 | |
| RATED SPEED rpm |
37500 | 36700 | 36050 | 45680 | 46380 | 46940 | 15000 | 20000 | 30000 | 15800 | 15000 | 14800 | 14300 | 14300 | 14100 | 25000 | 50000 | 50000 | |
| OUTPUT LEAD | Signal | Hall | Hall | Hall | Hall | Hall | Hall | ||||||||||||
| Product design |
|
|
|||||||||||||||||
| Product performance | - | - | |||||||||||||||||
| Product image |
|
|
|||||||||||||||||
| Motor model | VEC-28 series | VEC-32 series | |||||||||||||||||
| MOTOR | TYPE | EC2845 | EC2854 | EC2864 | EC3242 | EC3260 | EC3270 | ||||||||||||
| LENGTH"L" MM |
45mm | 54mm | 64mm | 42mm | 60mm | 70mm | |||||||||||||
| VOLTAGE | OPERATING RANGE |
10~14 | 22~26 | 32~38 | 10~14 | 22~26 | 32~38 | 10~14 | 22~26 | 32~38 | 16~20 | 22~26 | 32~38 | 16~20 | 22~26 | 32~38 | 16~20 | 22~26 | 32~38 |
| NOMINAL V |
12 | 24 | 36 | 12 | 24 | 36 | 12 | 24 | 36 | 18 | 24 | 36 | 18 | 24 | 36 | 18 | 24 | 36 | |
| OUTPUT | OUTPUT RATING W |
22.5 | 22.7 | 22.9 | 23.7 | 25.2 | 24.4 | 34.4 | 34.9 | 35.9 | 30.8 | 33.4 | 38.5 | 58.7 | 61.5 | 59.6 | 42.5 | 42.6 | 42.5 |
| RATED TORQUE m.Nm |
18 | 18 | 18 | 35 | 35 | 35 | 50 | 50 | 50 | 25 | 25 | 25 | 45 | 45 | 45 | 85 | 85 | 85 | |
| RATED SPEED rpm |
12200 | 12300 | 12400 | 6600 | 7000 | 6800 | 6700 | 6800 | 7000 | 12000 | 13000 | 15000 | 12700 | 13300 | 12900 | 4870 | 4880 | 4870 | |
| OUTPUT LEAD | Signal | Hall | Hall | Hall | Hall | Hall | Hall | ||||||||||||
| Product design |
|
|
|||||||||||||||||
| Product performance | - | - | |||||||||||||||||
VSD Coreless Brushless Motor
VSD has introduced a new range of Coreless Brushless Motors that offer high performance and versatility. The series covers 16, 19, 20, 22, 28 and 32 series with diameters ranging from the smallest of 30mm to the largest of 70mm to meet a wide range of applications.
Technical specifications and advantages
Rated voltage options: 6V, 12V, 24V, 36V.
Output models: Diverse designs including built-in drivers and Hall sensors.
High Efficiency Performance: The application of the latest motor manufacturing technology makes these Coreless Brushless Motors more efficient, low noise, fast response and high precision control.
Options: All models are available with encoders and planetary gearboxes for even greater versatility.
Applied to a wide range of household appliance scenarios
VSD Coreless Brushless Motors excel in household appliances, and their powerful performance is widely used in the following devices:
Fans: Improve operational efficiency and provide a smoother, quieter experience.
Vacuum cleaner: powerful adsorption and low noise operation combine to make cleaning more efficient.
Electric toothbrush: high speed and precise power output for a more comfortable brushing experience.
Blenders & Juicers: Smooth operation and long-lasting power to easily cope with a wide range of cooking needs.
Sweeping robots: support precise control and fast response, optimize navigation and cleaning ability.
Whether it's improving performance or optimizing the user experience, VSD Coreless Brushless Motors bring new possibilities to home appliances.
Why choose VSD's Coreless Brushless Motors
In the field of Coreless Brushless Motors, VSD has become a trusted brand in the industry due to its excellent customization capability and strict quality assurance. The following are the main reasons for choosing VSD Coreless Brushless Motors:
1. Strong customization capabilities
High percentage of customized customers: more than 90% of customers choose customized service, supporting OEM and ODM cooperation mode.
Rich experience and professional team: with more than 10 years of experience in the industry, equipped with dozens of senior R & D engineers, customized for customers to create the optimal motor program.
Versatile customization options: Motor parameters and materials can be customized according to requirements, including voltage, output power, speed, housing material, gear type, and protection class.
Sample and Rapid Production: Customized samples are provided and a dedicated sample workshop is set up. Production lead time for brushless motors is typically 15 to 25 days, depending on order quantity and demand.
2. Strict quality assurance
Factory certification: support online and offline factory inspection, the company has passed ISO 9001:2015, IATF16949:2016 and ISO14000 international quality management system certification.
Advanced testing capabilities: A product measurement center has been set up to perform a wide range of tests, including hardness measurements, comprehensive performance measurements, magnetic field distribution tests, leakage tests and magnetic flux density analysis.
Comprehensive quality testing: All motors are subjected to a series of rigorous tests for noise, waterproofing, longevity, crash, storage and salt spray.
Automated production line: The assembly line adopts advanced automation process, equipped with automatic winding machine, stator machine, end cap stator machine and soldering machine, which greatly improves the production efficiency and precision.
After-sales service guarantee: provide up to 12 months of product after-sales service, to ensure that customers have no worries.
VSD's Coreless Brushless Motors not only offer excellent customization capabilities, but are also known for their high quality and reliability, making them ideal for use in a wide range of fields, including household appliances, industrial equipment and smart devices.
