12v Coreless DC Motor

VSD's 12V Coreless Motor is a high-performance and highly customizable solution designed for a wide range of industrial and consumer applications. Our product line includes both Brushed and Brushless types, equipped with internal gear systems to deliver High torque output and precise servo control capabilities. As a lightweight 12V powerful Coreless DC Motor, it not only features low noise characteristics but also supports customization for speeds up to 50,000 rpm, meeting high-speed operation demands.



VSD's 12V Coreless Motor is manufactured using High quality materials, capable of withstanding variations in temperature, pressure, and vibration, ensuring exceptional durability and reliability. Additionally, we offer extensive customization options, including bearing types, lead lengths, terminal configurations, and even waterproof and anti-interference designs, guaranteeing stable motor performance in complex environments.



As a professional Manufacturer with over 10 years of experience, VSD operates a modern factory spanning over 10,000 square meters. In 2024, we further optimized our production processes, dividing Brushless and Brushed motor production into two independent workshops, achieving more efficient production management. We provide batch customization services to over 80% of our customers and can supply samples upon request. The sample fee can be refunded with a formal order, effectively offering a free trial experience.



Our motors are not only suitable for the compact design needs of mini devices but also meet the diverse requirements of High-performance servo control and DIY customization. With advanced testing equipment and strict quality control, VSD ensures that every motor leaving our factory meets the highest standards. Choose VSD for a reliable partnership.





VSD-2063 Coreless Motor

The VSD-2063 Coreless Motor is renowned for its high efficiency and exceptional performance, making it ideal for demanding applications. With a diameter of approximately 20 mm and a length of 63 mm, it supports rated voltages of 6V, 12V, and 24V, delivering a power range from 3W to 25W. At peak efficiency, it achieves speeds of up to 30,000 RPM, with an efficiency range of 85% to 90%. The hollow-cup design and coreless structure eliminate eddy currents and core losses, while providing high dynamic responsiveness for quick starts and stops-ideal for devices requiring precise motion. Additionally, its low noise and smooth operation make it particularly suitable for medical equipment where a quiet environment is essential.



With its lightweight design and outstanding reliability, the VSD-2063 Coreless Motor is widely applied in medical equipment, robotics, miniature drones, and high-end consumer electronics. Constructed from high-quality materials, it withstands extreme temperatures and vibration, operating within a temperature range of -10°C to +60°C, making it suitable for harsh industrial and commercial environments. The dual ball bearing design further extends the motor's lifespan and ensures operational stability. Combining robust power output, energy efficiency, and precise control, this motor is the optimal choice for lightweight and high-performance devices.



VSD-2063 Coreless Motor Design





VSD-2845 Coreless Motor

The VSD-2845 Coreless Motor, with its compact dimensions (28 mm in diameter and 45 mm in length) and lightweight design (approximately 90 grams), is an ideal choice for lightweight, high-performance applications. It supports typical operating voltages of 12V and 24V, reaching a maximum speed of 12,200 RPM at 12V and 12,300 RPM at 24V, while delivering stable power outputs of 22.5W to 22.9W. The high-efficiency design (85%-93%) significantly reduces energy loss, and with a peak torque of 18 mNm, it provides outstanding power performance. The dual ball bearing construction extends the motor's lifespan to 2,000 hours, ensuring smoother and quieter operation, making it perfect for equipment requiring high reliability and precision control.



Thanks to its exceptional performance, the VSD-2845 Coreless Motor finds broad applications in medical equipment (such as infusion pumps and surgical robots), consumer electronics (such as power tools and drones), industrial automation (such as servo control systems), robotics, and the automotive sector. Its lightweight and low-noise characteristics make it particularly suitable for sound-sensitive and weight-critical scenarios, while precise speed and position control allow it to excel in complex motion tasks. Whether in service robots or automated equipment, this motor provides customers with optimal solutions in terms of stability and efficiency.



VSD-2845 Coreless Motor Design



VSD-2864 Coreless Motor

The VSD-2864 Coreless Motor stands out with its compact dimensions of 28 mm in diameter and 64 mm in length, paired with an ultra-lightweight design of just 20-30 grams. Featuring a coreless structure with a honeycomb ring design, it significantly reduces motor inertia, delivering exceptional speeds of up to 12,400 RPM with nearly 90% efficiency. Its low noise and low current consumption make it an ideal choice for sound-sensitive or long-operation devices, particularly in battery-powered applications. Additionally, the coreless design minimizes sparking and electromagnetic interference (EMI), ensuring operational stability and precise current control.



This motor is widely utilized in drones and small aircraft, meeting the demands for extended flight times with its high power-to-weight ratio and rapid response. In medical equipment, its low noise and high reliability make it suitable for insulin pumps and laboratory instruments. In robotics and precision instruments, the VSD-2864 Coreless Motor supports fast and accurate motion control for applications such as robotic arms, joints, and miniature actuators. Furthermore, it is widely used in small pumps and precision tools, delivering efficient and reliable drive solutions to customers.





The 12V Coreless Motor , with its unique design and outstanding performance, is widely used across multiple fields.



Iron-loss-free Design

The coreless structure with a hollow cup design eliminates the iron loss and eddy current effects found in traditional motors. This design significantly improves motor efficiency, achieving an efficiency range of 85% to 93%. It ensures lower energy loss under the same power, fully meeting the needs of high-efficiency and energy-saving applications.



High Dynamic Response

Thanks to the reduced rotor inertia of the coreless structure, the motor's acceleration and deceleration response speeds are greatly enhanced. It is highly suitable for precision devices requiring rapid response, such as medical instruments, robotics, and industrial automation equipment.



Smooth Operation and Low Noise

The 12V Coreless Motor operates without cogging effects, ensuring smoother rotational speeds. Additionally, the coreless design effectively reduces noise, making it ideal for medical equipment and other environments with strict noise requirements.



Low Current Consumption, Ideal for Battery-powered Devices

The coreless design drastically reduces current consumption, allowing the motor to perform exceptionally in battery-powered devices. It is especially suitable for applications requiring long operational durations, such as drones and consumer electronics.



Lightweight Design

The motor features a compact structure and lightweight build, making it an ideal choice for weight-sensitive devices such as micro aircraft, handheld devices, and portable instruments.



Precise Control

Supports high-precision speed and position control, meeting the stringent requirements for precise motion in applications like servo systems and robotic joints.



Durability and Reliability

Built with High quality materials, the motor is capable of withstanding variations in temperature, pressure, and vibration, ensuring long-term stable operation. Moreover, the coreless structure minimizes sparks and electromagnetic interference (EMI) between brushes and commutators, further enhancing device reliability.



Energy-saving and Environmentally Friendly

With low energy consumption and high efficiency, VSD's 12V Coreless Motor reduces energy costs for users while minimizing environmental impact.



With these features, VSD's 12V Coreless Motor demonstrates unparalleled performance and adaptability. Whether for noise-sensitive medical equipment or high dynamic response needs in small drones, this motor offers a reliable solution. It is the ideal choice for lightweight, high-precision, and energy-saving applications.





The 12V Coreless Motor is widely used across various fields due to its lightweight design, high power-to-weight ratio, low noise, and precise control capabilities, meeting the demands of high-precision and specialized applications.



Medical Equipment

VSD's 12V Coreless Motor is renowned for its high reliability and stability, making it an indispensable key component in medical equipment. For example, these motors are used in infusion pumps, surgical tools, insulin pumps, X-ray machines, dialysis devices, and laboratory instruments. Their low noise and precise control capabilities ensure efficient operation during critical tasks while providing quiet and stable support in medical environments.



Robotics

In the robotics field, VSD's 12V Coreless Motor is commonly employed in service robots, research robots, and industrial automation equipment. Its fast response, smooth motion, and High torque characteristics make it ideal for robotic arms, joints, and wheel drives. Whether for actuators or high-precision components, this motor delivers exceptional performance.



Miniature Drones and Aircraft

With its high power-to-weight ratio and high-speed capabilities, VSD's 12V Coreless Motor is perfectly suited for miniature drones and micro aircraft. These motors provide powerful support while extending flight times, making them widely applicable in scenarios requiring lightweight and high-efficiency solutions, such as model aircraft and professional-grade drones.



Consumer Electronics

In the consumer electronics sector, this motor finds applications in high-end audio equipment, electronic locks, gaming devices, small pump systems, and power tools. Its lightweight design and precise performance make it an ideal drive solution for modern consumer demands.



Instrumentation and Industrial Automation

VSD's 12V Coreless Motor is often used in laboratory equipment, printers, and other precision instruments. Additionally, in industrial automation, the motor's servo control capabilities enhance efficiency and accuracy, making it a reliable choice for automation control and sensor-driven applications.



Automotive Industry

The 12V Coreless Motor , with its compact structure and stable performance, is widely applied in the automotive industry, particularly in automation control and sensor systems, helping to optimize driving experiences and vehicle performance.



Other Lightweight Applications

VSD's 12V Coreless Motor is also suitable for model aircraft, electric toys, and customized drive systems, perfectly supporting various scenarios requiring miniaturization and high performance.



Whether for demanding medical equipment, innovative consumer electronics, or advanced robotics, VSD's 12V Coreless Motor provides reliable power solutions with its superior performance and extensive customization options, serving a wide range of industries.





1. Professional R&D Team with Strong Customization Capabilities

VSD boasts a research and development team of over 20 experienced designers and developers, investing more than 2 million RMB annually in technological development and product innovation. Whether you require customization for motor power, speed, bearing type, dimensions, or specialized features (such as waterproofing, shock resistance, or anti-interference designs), we can create tailored solutions to meet your needs, ranging from small-scale DIY customizations to large-scale bulk production.



2. Robust Manufacturing Capabilities for Efficient Delivery

Equipped with over 100 advanced manufacturing machines, including laser automatic slotting machines, automatic balancing machines, brushless automatic winding machines, and automatic pressure welding machines, VSD ensures efficiency throughout the production process. In 2024, we further optimized our production line by separating the hollow-cup brushless motor production into dedicated workshops, enhancing standardization and efficiency.

3. Stringent Quality Control System

To guarantee the quality of every 12V coreless motor, we have established a comprehensive testing system. Our facilities are equipped with torque testers, roundness testers, roughness testers, comprehensive performance testers, vibration testers, and more. We also conduct precise tests for magnetic field distribution, flux density, and hardness to ensure that every product meets the highest performance standards.



4. Flexible Procurement Options with Transparent Pricing

Whether you are looking for bulk purchases, customized (DIY) solutions, or a reliable long-term supplier, VSD offers flexible purchasing options. Our transparent pricing system ensures that customers have a clear understanding of all costs, delivering high-quality products with excellent cost-performance ratios.



5. Reliable Wholesale Supply and After-Sales Support

As a professional supplier of 12V coreless motors, VSD supports wholesale purchases with dependable delivery schedules and consistent supply capabilities. Our dedicated team provides comprehensive technical support and after-sales services, addressing any concerns to ensure a seamless user experience.
