12V 24V Micro Gear Motor

Reducer motor refers to the integration of reducer and motor (motor). This kind of integration can also be called gear motor or gear motor. Gear reduction motor is the abbreviation of the combination of motor and reducer. It is to use n groups of gears with different number of teeth to reduce the output shaft speed of the motor to the speed you need. Gear reduction motor can be fully used with rotary encoder. 12V 24V Micro Gear Motor diameter range is 6-70 mm, the rotational speed is 5-1500 rpm, the energy consumption is low, the performance is superior, the efficiency is more than 95%, the vibration is small, the noise is low, the energy saving is high, and the gear module can be customized.

Company Highlights



Overview



Warranty	3 months - 1 year
Place of Origin	Shenzhen, China
Brand Name	Vshida
Model Number	VSD-G370
Usage	Water pump,air pump,small home appliances,sports,medical,Beauty,electric tools,robots,etc.
Type	Gear motor
Weight	TBD (different ratio different weight)
Components	Diversifed
Construction	Permanent Magnet
Commutation	Brushless/Brush
Protect Feature	Customized(Waterproof, Fireproof, Totally closed）
Efficiency	86%
Bearing	D-shaft,ball bearing,oil bearing
Rated speed	5-1500 (rpm)(Customized）
Rated Voltage	12 (V)
Load current	1 A
Voltage range	≤48 V
Size	42*60 (mm)
Payment terms	30% advance, 70% balance
Certificate	IATF16949
Customized	Acceped

Product Description

We have a professional R&D team,Invest a fixed amount of money in R&D and production every year to meet customers' customization needs and OEM/ODM needs. The engineer will give you the most professional advice and look forward to your inquiry.



Motor Parameter

VOLTAGE	NO LOAD		AT MAXIMUM EFFICIENCY				STARTING
NOMINAL V	SPEED r/min	CURRENT A	SPEED r/min	CURRENT A	TORQUE mN.m	OUTPUT W	TORQUE mN.m	CURRENT A
12	166	0.36	125	1.092	448.677	5.866	1809	3.31
24	352	0.36	286	1.544	725.953	21.715	3839	6.62

Product Size

Performance Curve

The above reducer parameters are for reference only. Can be customized according to the customer's needs. The parameters such as speed, voltage, power, lead wire, lead wire terminal, bearing, etc. can be customized. If you need to match the encoder, gearbox, driver, please contact us.



Product Features

1. The transmission ratio classification is fine, the selection range is wide, and the speed type spectrum is wide.

2. The reducer motor has compact structure, small size, beautiful shape, strong overload resistance, space saving, long service life and durability.

3. Low energy consumption, low noise, energy conservation and environmental protection, superior performance and low vibration.

4. It has strong versatility, is easy to use and maintain, and low maintenance cost. Especially for the production line, only a few internal transmission parts need to be reserved for normal production of the whole line.

5. Adopt modular design and sealing device, with good protection performance and strong adaptability to the environment.

6. The motor coil is made of pure copper, with low resistivity, good conductivity, high strength and low power consumption;

7. Made of high-quality aluminum, it is corrosion resistant, not easy to rust, and reliable in performance. It has low heat and high output efficiency

8. There are two brush feet at the bottom, which is more convenient to complete various welding processes. At the same time, wiring is more convenient;

9. The central shaft is processed by numerical control, which increases the friction force, makes the transmission more stable and the connection more fixed;

Company Strength

Vshida Micro Motor Co., Ltd. is a company specializing in the production and sales of various motors. The company's products cover brush motors, brushless motors, speed reduction motors, hollow cup motors, pumps, air gun motors, etc. There are more than 600 employees, more than 40 production lines, more than 300 detection equipment, and more than 200000 daily motors. We have continuously launched high-quality, high-performance and high-efficiency test equipment products, which have won the praise and trust of many customers. At present, we have become one of the leading enterprises in the motor industry at home and abroad. In the future, we will continue to work hard to provide customers with more high-quality products and services.

All motors will undergo a series of performance tests before leaving the factory to ensure compliance with customer requirements, reduce the proportion of defective products, and improve production efficiency with more than 300 sets of automatic production equipment. Contact me to get samples for performance test.



Product Certificate

With our efforts, we have obtained a number of international and patent certifications to meet the requirements of different customers for motor certificates. If you need other certificates, please contact me to obtain them.

Some of our partners

We have provided many international famous brands with micro motors, pumps, etc. We have been working hard and never choose to give up. We look forward to becoming your partner.

Application

Gear reducers are mainly used in metallurgy, ports, mines, lifting, transportation, cement, construction, chemical, textile, printing and dyeing, pharmaceuticals, heavy machinery and other fields.

Why choose us

Transport Packing

Shockproof foam packaging is adopted. If you need specific packaging services, please contact us in advance.

Inner packaging of foam box: 350*265*280mm
Carton outer packaging: 365*275*320mm
Weight 16.7kg/350pcs

Payment & Delivery





Difference between 12V 24V micro gear motor and ordinary motor

The reduction motor is the reducer. It is the integration of the reducer and the motor. It has both the driving ability and the reduction function. It is designed to reduce/reduce the speed. It is a power transmission mechanism. It can use the speed converter of the gear to reduce the number of revolutions of the motor to the required number of revolutions, and obtain a larger torque. It is usually supplied in a complete set after being integrated and assembled by a professional reducer manufacturer.

Generally speaking, the common motor is the driver. It is the main source of power and has no deceleration function. It is a device that converts electrical energy into mechanical energy. It can use the energized coil (i.e. stator winding) to generate a rotating magnetic field and act on the rotor (such as squirrel-cage closed aluminum frame) to form a magnetoelectric rotating torque. The motor, commonly known as "motor", is represented by the letter "M" in the circuit ("D" in the old standard). Its main function is to generate driving torque, as the power source of electrical appliances or various machinery. The generator is represented by the letter "G" in the circuit.
