22mm Micro Planetary Brushless Gear Motor

22mm micro planetary brushless gear motor rated voltage: 12V, no-load current: 400mA, no-load speed: 60RPM, applicable voltage: DC 3V-15V, torque: 400mNm (0.4NM), reduction ratio: 102:1, weight: 95g; It can be easily installed and replaced without any tools, and has a fully enclosed structure. Made of high-quality materials, permanent magnets make the motor run more stably. Gear motors have a large number of high-speed gears that can be replaced at any time. More importantly, the gear motor has the characteristics of low noise, high torque, low power consumption, and high efficiency; parameters such as bearings, speed, voltage, power, and size can be customized according to customer needs.

Company Highlights



Overview

Warranty	3 months - 1 year
Place of Origin	Shenzhen, China
Brand Name	Vshida
Model Number	VSD-G2246
Usage	Robots, door locks, automatic blinds, USB fans, currency detectors, towel racks, peritoneal machines, office equipment, household appliances, automation, medical screwdrivers, laboratory mixers, beauty instruments, medical equipment, hairdressing equipment, etc.
Type	Gear motor/BLDC Motor
Weight	TBD (different ratio different weight)
Components	Diversifed
Construction	Permanent Magnet
Commutation	Brushless
Protect Feature	Customized(Waterproof, Fireproof, Fully Enclosed）
Efficiency	82%
Shast Type	D-Shaft（Can be customized according to customer needs）
Direction of Rotation	CW/CCW
Rated speed	6-1500 (rpm)
Rated Voltage	12 (V)
Start Current	0.25 A
Dimensions	22*46 (mm)
Payment terms	30% advance, 70% balance
Certificate	IAFT16949
Customized	Acceped

Product Description

We have strong research and development capabilities, and can develop a variety of new motors in a short period of time to meet customer customization needs and large-volume orders.

Product Parameter

Product Size

Performance Curve

The information above is just intended to be used as a general reference; customers are free to modify and adapt the exact parameters of the geared motor as required.

Product Details

	100% actual photos
The motor coil was made of pure copper, which has excellent electrical conductivity, low resistance, great strength, and less heat generation.		A variety of welding activities can be made easier thanks to the motor's ingenious construction at the bottom. enhanced heat dissipation, a fixed rotor, better matching, and longer service life.

Gear Motor Description

1. The size and shape of the output shaft can be customized, the shaft can be D-Cut, with holes, screw holes, etc., and the output shaft is the central shaft. .
2. Input speed can be customized. The gear ratio can also be changed, so a geared motor can have a different final output speed.
3. The 22mm Micro Planetary Brushless Gear Motor is a precision permanent magnet carbon brushless DC motor, and it can also be equipped with a brushless DC motor.
4. The working voltage can be 6V, 9V, 12V 15V 18V 24V.
5. If you have different speed and torque requirements, you can adjust this gearbox to match with other types of DC motors.
6. The gearbox is a planetary gearbox, which is widely used in various micro automation industries. Main function - Deceleration of high-speed DC motor through gear reduction.
7. The main features of this type of geared motor - low noise, long life, low speed, high torque.



Company Strength

The Vshida Micro Motor Company not only uses cutting-edge technologies for research, development, and production, but also cutting-edge production management strategies. has obtained certification for the quality management systems ISO 9001:2015 and IATF16949:2016. With a floor area of more than 10,000 square meters, more than 500 employees, more than 300 sets of automation equipment, more than 40 assembly lines, 30 R&D personnel, and a daily output of roughly 200,000 motors.The company's current manufacturing plant is equipped to meet large orders and customer customization requirements.



Product Certificate

In order to satisfy client requests for a variety of certifications, Vshida Micro Motor has successfully completed a number of international certifications and patent certifications.

Some of our partners

As a reliable partner in China, we are glad to cooperate with you. We insist on providing quality assurance for gear motors. Choosing to cooperate with us is choosing to use high-quality products. Looking forward to your inquiry.

Why choose us?

Application

22mm Micro Planetary Brushless Gear Motor are extremely versatile and can be created for a variety of application scenarios. If you have any exceptional requirements, get in touch with us.

Transport Packing

Packaging Details：Inner packaging of foam box: 350*265*280mm;Carton outer packaging: 365*275*320mm;Weight 16.7kg/350pcs

To strengthen the outside packing, start by using nylon packaging, followed by carton packaging, and finally wooden boxes. or packaged in accordance with customer demands.

Payment & Delivery

FAQ

1. What kind of DC motor/gear motor do you offer?
A: A full range of small wheel box DC motor packages, the diameter range is 6mm 8mm 10mm12 mm13 mm1 m20mm22 mm24mm2mm. 32 mm, 36 mm, 37 mm, 42 mm, 45 mm, 57mm and so on. Long service life, reliable and stable operation.
2. If we can provide the mold cost, can you develop new motors?
A: Yes. Please share detailed requirements, such as performance, size, annual output, target price, etc. We will then evaluate and advise you
3. Can I get some samples?
A: Most of our samples are free for you, some expensive motors we charge twice the price of the bulk order. Don't worry, the sample fee will be refunded as the motor payment when you place a mass production order.
4. When will you reply me?
A: Our customer service staff will reply you within 12 hours
5. Can you give me a price list?
A For all our small DC motors and wheel motors, they are all different to be customized, such as life, power, voltage, etc. The price also varies according to different quantities. So it's hard for us to provide the price list, if you can share your detailed requirements and quantity, then we can send you the specified DC motor pricing.
