flat brushless dc motor

flat brushless dc motor Product specification: 20MM, voltage: 12V, no-load speed: 15000rpm-30000rpm (can be customized), no-load current: 220 mA (can be customized), load speed: 2.4-1000 rpm (can be customized), deceleration Ratio: 5/25/125/625:1 (customizable), drive motor: brushless motor (hollow cup motor, brush motor, stepper motor, etc.), reduction gearbox: planetary gearbox, with low output speed, It has the characteristics of high torque, low noise and long life. It is mainly assembled by a micro drive motor and a reduction gear box mechanism. The technical parameters of the electric toothbrush motor are usually customized and developed according to the needs.



Company Highlights

Overview

Warranty	3months-1year
Place of Origin	Shenzhen, China
Brand Name	Vshida
Usage	Smart home, electric toothbrush, drone, robot, medical equipment, industry, etc.etc.
Type	Micro motor
Weight	TBD (different ratio different weight)
Components	Diversifed
Construction	Permanent Magnet
Commutation	Brushless
Protect Feature	Customized(Fireproof, watertight, completely enclosed)
Efficiency	83%
Voltage range	≤36 V
Product Name	Micro  Brushless dc motor
Rated Voltage	DC 3.7 V
Direction of rotation	CCW CW
Payment terms	30% advance, 70% balance
Dimensions	16*20(mm)
Critificate	CE
Customized	Acceped

Product Description

Please get in touch with us if the consumer has any additional needs. Your inquiries will receive a 24-hour online response from us. The customer's requirements can be satisfied by adjusting all technical parameters.

Motor Parameter



Motor Performance Curve

Product Details

	100% actual photos
Rotor:comprised of a high-quality iron core with exceptional temperature resistance wrapped around a pure copper wire. Additionally, it has a lower current resistance and requires less energy.		Bearings: Use branded bearings to assure quality and reduce motor noise (bearings can be customized)
	100% actual photos
End cap:Use premium raw materials to increase lifespan, repair the motor's rotor, and enhance heat dissipation.		Chassis:Using high-quality materials with high hardness, high temperature resistance, corrosion resistance, wear resistance, and rust resistance increases the service life.

Description of the motor



1. Use high quality waterproof hollow cup vibration motor to better help your replacement or DIY, waterproof

2. Motor specification: Voltage 1.5-3V; Speed: 5000-24000; Power: 0.01-0.06 W Torque: 0.01 oz.cm-0.11 oz.cm (NM)

3. Motors are widely used in various electronic vibration equipment, such as toys, dental equipment, beauty products, personal care, remote control cars, airplanes and other supplies.

4. Easy to install and store. When not in use, it can be placed in a sealed bag to prevent moisture and rust.

5. Features of flat brushless dc motor: very quiet operation, small size, high efficiency, fast speed and stable operation. Using steel shell, not easy to rust, durable and stable performance.



Company Strength

With our independent R&D team, mature process design, and 15 years of motor R&D and manufacturing experience, choosing to work with us is choosing to work with a well-thought-out, high-quality manufacturer.



Product Certificate



Some of our partners



Application

We are pleased to work with you in China as a long-term partner. We have dedicated a lot of work to developing DC motors, serving the majority of the European and American markets, all in an effort to give clients the best motors and services possible.

Transport Packing

Supply Capacity: More than 200000 DC motors with  per Day

Foam box inside dimensions are 350x265x280mm.

Dimensions of the outer carton: 365*275*320mm.

350 pieces; 16.7 kilogram

Please get in touch with us if you have any further specific packaging needs.

Payment & Delivery

FAQ

Can I utilize a motor designed for a 12V application?

A: Please provide more information, such as motor size, speed, and torque. If you could provide us images with dimensions indicated or thorough data sheets, that would be excellent. A motor's type cannot be determined just by voltage and application.



Can you disclose the motor's lifespan?

A: Because all of our motors are designed to meet specific needs, there is no set service life. The load that you put on the motor also has an impact on your life. When we set up the samples, we will take into consideration the selection of suitable motors and materials to satisfy customer needs. Typically, our customers will first supply the life requirements, noise level, etc. Customers will be put through lifelong testing in their lab, and orders will be placed according to the samples that pass.



Are accessories like cables, connections, gears, encoders, etc. available from you?

A: We can, yes. If these aren't typical, more money might be needed for molding.



What varieties of encoders do you offer? What's the outcome?

A: Depending on the required resolution, we can offer both magnetic and optical encoders (3PPR, 12PPR, 13PPR, 100PPR, etc.). If not present, further cost charges might be incurred.



What types of certificates do you provide?

The fundamental certification is ROHS. We can offer REACH, CE, etc. for other components. Please let us know if you need us to offer any other certification.
