2207 High Speed Drone Motor

High speed drone motors play a key role in drone flight, significantly improving maneuverability, stability and responsiveness. VSD's VSD-2207 brushless FPV motor, for example, this class of motor can significantly enhance the flexibility and stability of drones in flight. The design of high rotational speed and high power density enables the UAV to maintain stable and rapid response during complex flight actions, such as rapid dives, rolls and power loops, thereby improving the accuracy of operation and the overall flight experience.



The advantages of the VSD-2207 motor are not only reflected in its efficient performance, but also in its unique external rotor structure and direct drive technology. This design allows the motor to have lower noise when rotating at high speeds, while optimizing power transmission and reducing intermediate mechanical losses. For the pilot, this means a smoother and more consistent flying experience, especially during intense racing or aerobatics, where the motor's fast response facilitates precise operation.



There is also a special focus on durability and reliability with VSD's high speed drone motor. The VSD-2207 features a water-resistant design and IP53 dust-proof double bearing for stable performance, even in wet or dusty environments. The lightweight design of the motor and the robust aluminum alloy housing enable it to reduce the overall weight while improving the heat dissipation efficiency and reducing the risk of overheating. This not only extends the service life of the motor, but also increases the endurance of the drone, which is suitable for use in long, high-intensity flights.



With its excellent performance of high RPM and high power density, the VSD-2207 motor has become an ideal choice for professional pilots and drone enthusiasts. Its innovative external rotor structure and well-designed direct drive system provide users with a stable and efficient power source. VSD's high speed drone motor not only achieves an excellent level of performance, but also meets different challenges and needs in flight in terms of durability, low noise and water resistance.





Design drawing



Test data

Motor Type	PROPS	Throttle	Voltage(V)	Current(A)	Thrust(g)	RPM	Power(W)	Efficiency(g/W)	Operating Temperature (℃)
VSD-2207 1960KV	BB4943.5	30%	23.98	2.35	197.8	12032	56.35	3.51	45.7℃
		40%	23.95	4.71	344.3	15668	112.8	3.05
		50%	23.93	7.96	528.7	19138	190.48	2.78
		60%	23.81	11.91	712.8	22048	283.58	2.51
		70%	23.79	17.06	938.1	25014	405.86	2.31
		80%	23.65	22.04	1160.3	27419	521.25	2.23
		90%	23.54	29.28	1449.6	30444	689.25	2.1
		100%	23.39	36.78	1646.3	32528	860.28	1.91
	51466	30%	23.94	2.44	209.9	11998	58.41	3.59	94℃
		40%	23.89	4.75	366.4	15554	113.48	3.23
		50%	23.84	8.26	562.1	18926	196.92	2.85
		60%	23.79	12.54	778.7	21823	298.33	2.61
		70%	23.7	17.77	1021.9	24653	421.15	2.43
		80%	23.57	23.4	1241.1	26902	551.54	2.25
		90%	23.46	30.96	1545	29808	726.32	2.13
		100%	23.35	38.65	1702.7	31802	902.48	1.89





In competitive drone and FPV (first Person View) flight, the motor is one of the core components that determines flight performance. Designed for extreme flight, the VSD-2207 high speed drone motor delivers high performance and extreme durability, perfectly adapted to the demands of high thrust and precise control, helping pilots push the limits and control every moment of flight.



1. Powerful thrust, fast response

The VSD-2207 drone motor delivers up to 1,720g of thrust, ensuring strong performance at full throttle. Whether it is a high-altitude dive or a fast roll, it helps pilots complete the most complex flight maneuvers with precise control and extremely high response speed. There are also two KV value options, 1850KV and 1950KV, to meet different flight needs, especially suitable for those who require rapid reaction and extremely high thrust racing or aerobatic scenarios.



2. Efficient heat dissipation and stable operation

In the process of high-speed flight for a long time, the heat dissipation performance of the motor is crucial. VSD-2207 drone motor adopts aluminum alloy shell and optimized heat dissipation structure design to ensure that the motor can quickly cool down when running at high speed and avoid overheating leading to performance decline. Excellent heat dissipation performance makes it still maintain stable operation under high load conditions, suitable for long-term high-intensity competitive flight.



3. Impact resistance, limit flight worry-free

Frequent collisions and landings are inevitable challenges in competitive FPV flying. The unique ratcheted upper cover design of the VSD-2207 drone motor significantly improves the motor's impact resistance and reduces damage caused by collisions. Whether it's intense aerial acrobatic maneuverings or complex low-altitude crossings, the VSD-2207 drone motor can withstand extreme impact, providing additional protection for the pilot.



4. Lightweight design, improve mobility

In FPV racing, maneuverability is one of the key factors to decide the outcome. The VSD-2207 drone motor uses a lightweight design to provide strong thrust without adding excess weight, thus improving the drone's flexibility and response speed. The lightweight motor not only optimizes the pilot's operating experience, but also effectively prolongs flight time, making competitive flight more durable and stable.



5. High-precision control to unlock extreme tricks

Competitive FPV flight requires extremely high precision control of the motor. The VSD-2207 drone motor provides smooth power output and precise response, whether it's tumbling, spiraling or turning at high speed, ensuring the pilot gets immediate feedback and control. This high-precision control capability makes the VSD-2207 drone motor ideal for pursuing extreme freestyle flying skills.



6. Waterproof and dust-proof, adaptable to changing environments

FPV drones often fly in different environments, and weather changes and harsh conditions may affect the performance of the motor. VSD-2207 UAV motor adopts IP53 dustproof and waterproof design to effectively prevent the intrusion of water and dust, and ensure the stable operation of the motor in a wet or dusty environment. This feature makes it particularly suitable for outdoor competition and extreme flight scenarios.



7. Porous installation design, strong compatibility

VSD-2207 drone motor motor has a porous mounting design, compatible with most drone frames on the market. No matter what kind of rack you are using, the VSD-2207 drone motor is easy to install and guarantees a perfect fit with other components. In addition, the motor's optimized structural design helps to improve heat dissipation efficiency, ensuring that the motor maintains excellent performance in competitive flight.



8. High temperature tolerance, continuous efficient performance

To cope with intense flight conditions, the VSD-2207 drone motor is equipped with heat-resistant copper wires and powerful magnets, capable of continuously providing stable power output under high load and high temperature conditions. This design makes the motor less prone to performance degradation due to overheating during long-term high-speed flight, making it suitable for demanding competitive and aerobatic flying.



9. Unique propeller locking mechanism to enhance safety

The VSD-2207 drone motor is equipped with a unique propeller locking mechanism to effectively avoid loose or sliding propellers during high-pressure flight. This design can greatly improve flight safety, especially during fast turns and heavy maneuvers, ensuring that the pilot can focus on the flight without worrying about equipment failure.



With its strong thrust, excellent heat dissipation, impact-resistant design and high-precision control, the VSD-2207 drone motor perfectly meets the stringent motor requirements for competitive drone and FPV flight. Whether you are a beginner or a professional pilot, the VSD-2207 drone motor provides unmatched support for your flight, helping you easily unlock the ultimate flying skills and create the ultimate flying experience.





In order to meet the changing market demand and personalized flight needs, the customized production process of high speed drone motor is particularly important. As a leading manufacturer of high speed drone motor, VSD provides high-quality, high-performance motors, and provides customized design services according to the specific needs of customers, ensuring that each motor can be perfectly adapted to different flight scenarios and needs.



high speed drone motor customizes the production process



1. Determine motor size and design

The first step in custom production is to determine the size and design of the motor. This process is the responsibility of a professional R & D team, the designer will be based on customer needs, flight requirements and restrictions to design, to ensure that each motor can meet the high performance, high precision flight standards. The size, KV value, speed, etc. of the motor will be precisely calculated and adjusted to optimize flight performance.



2. Motor copper wire making and winding

Into the production link, the second step is to make the copper wire of the motor. In order to increase the winding space of the motor, the manufacturing team will precisely thread the copper wire into the inner coil and wrap the small copper wire around the outside. Then, by coating the adhesive, each copper wire is securely secured to ensure the motor's stability and high performance.



3. Process the motor housing

The next step is to process the motor housing. Large automated machines are used for machining, ensuring the precision and high quality standards of the housing. The motor shell not only needs to have a strong protection function, but also needs to consider the heat dissipation design, so every detail needs to be strictly controlled.



4. Install the internal components

At this stage, all necessary internal components such as magnets, shaft rotors, axial flow fans, and governors will be carefully installed into the interior of the motor. These components are essential for the operation of the motor, and each installation must be done accurately to ensure that the motor is stable and efficient at high speeds.



5. Quality control and testing

The final link is to carry out strict quality control and testing of the motor. Every motor needs to undergo a comprehensive performance test to ensure that it can meet the design requirements and provide a stable power output. As the high speed drone motor is related to the safety of flight, VSD attaches great importance to this link and strictly checks every detail to ensure that each motor meets high standards of safety requirements.



VSD high-speed drone motor manufacturer

As the industry's leading manufacturer of high speed drone motor, VSD not only has deep technical accumulation in the development and production of motors, but also provides customers with extremely flexible solutions in terms of customized services. With customers as the center, VSD is committed to developing high-performance motors to meet different flight needs.



Extensive selection of motor models

In addition to the popular VSD-2207 motor, VSD also offers several models, such as 2306, 2208, 2806, 2807, 2810, 3110, 3115, etc., capable of providing suitable motor options for various types of drones. These motors are not only suitable for FPV flight and competitive racing, but also can cope with a variety of complex flight missions.



Strong production capacity and facilities

VSD has its own production plant of more than 10,000 square meters, equipped with 40+ high-efficiency production lines, with a monthly output of more than 4,500,000 DC motors. Regardless of the size of the order, VSD ensures timely delivery and offers both online and offline factory visits to ensure transparency and trust in the production process.



Continuous innovation and R&D investment

VSD's R&D team consists of a group of experienced engineers and designers who invest a lot of money in technology research and development every year. VSD launches a new type of motor every two months and is always at the forefront of industry technology to ensure that products are always industry-competitive.



Customized design with OEM/ODM services

VSD is committed to providing personalized customization services, and can customize the design according to the specific needs of customers, ensuring that each motor is perfectly adapted to the customer's aircraft. Whether OEM or ODM needs, VSD can provide customers with a one-stop solution to help customers quickly launch motor products that meet the market needs.



Whether you need a customized high speed drone motor or are interested in VSD's products, we are more than happy to provide you with professional consultation and service. Our team will provide personalized motor solutions according to your needs, ensuring that your aircraft can achieve the best performance in terms of performance and stability.



If you have any questions or needs, please feel free to contact us! Just leave your email and phone number and we will provide you with a detailed quote and technical support as soon as possible.
