Epicyclic Gear Motor

VSD's Epicyclic Gear Motor adopts an advanced epicyclic gear structure, featuring key components such as the sun gear, planet gears, and ring gear. Its full-steel gear design ensures high wear resistance, enabling long-term efficient operation under high-torque loads. This epicyclic gear motor offers various customization options, including gear material, structure, and reduction ratio, allowing customers to tailor the product to their needs. Especially in the brushless DC series, our epicyclic gear motor achieves a longer lifespan and smoother performance.



The epicyclic gear motor provides high power and high torque output, capable of offering strong overload resistance, distributing and transmitting loads, and withstanding excess pressure without damage. Whether for high-load applications or precise speed and position control, VSD's epicyclic gear motor ensures efficient and stable power output. Compared to other motors, the epicyclic gear motor has a lower starting current, making the startup process smoother and more energy-efficient.



VSD's epicyclic gear motor is suitable for various applications with 12V and 24V voltages, especially performing excellently in micro, servo, and stepper control fields. It provides excellent reduction performance, enabling precise speed control, and maintains stable operation even under extreme conditions, making it ideal for use in harsh environments. If your application requires a higher level of protection, VSD also offers IP65 and IP67 protection-grade custom options, featuring outstanding dustproof, waterproof, and corrosion-resistant properties.



VSD has an independent R&D team and advanced production equipment, enabling us to provide customers with comprehensive OEM/ODM customization services. We invest heavily each year in new product development to ensure we meet the diverse needs of our customers. Additionally, all motors undergo strict quality testing, including noise testing, waterproof testing, lifetime testing, etc., ensuring that every motor provides reliable performance and long-lasting durability.



Whether you need high-precision stepper control or high-power DC drive, VSD's epicyclic gear motor provides the ideal solution. We support various customization options and offer free samples to help customers verify the compatibility and performance of the product before placing formal orders.





GM20-130SH Epicyclic Gear Motor

VSD's GM20-130SH epicyclic gear motor, with its high efficiency, customization options, and stable performance, is the ideal choice for various precision applications. This epicyclic gear motor offers two specifications: 6V and 12V versions, with rated speed of 5600r/min and 5900r/min, respectively, meeting the high-efficiency operation requirements under different load conditions. Its high torque and low noise characteristics make it especially outstanding in driving systems. Notably, the motor can withstand a stall torque of up to 65 g.cm (6V version) and 70 g.cm (12V version), providing stable power output even under high loads.



In addition, VSD's epicyclic gear motor offers customizable reduction ratios ranging from 29 to 488, allowing customers to adjust the reduction ratio to achieve more precise control and higher efficiency. These features make the motor widely used in driving wheels or tracks, service robots, and other fields, suitable for drive systems that require high precision and powerful output. Whether in indoor or outdoor robotic drives, mobile platforms, or automated equipment, VSD's GM20-130SH epicyclic gear motor can provide your project with stable, long-lasting support.



GM20-130SH Gear Motor Design

GM20-130SH Gear Motor Performance



YGA37BL3626 Epicyclic Gear Motor

VSD's YGA37BL3626 epicyclic gear motor, with its excellent high torque and high efficiency, becomes the ideal choice for various high-load drive systems. It offers two specifications: the 12V version has a rated voltage of 12V, delivering a torque of up to 448.677 mN·m at the maximum power speed of 125 r/min, while the 24V version can provide a stronger 725.953 mN·m torque at the maximum power speed of 286 r/min, with a maximum power of 21.715W. This makes the VSD epicyclic gear motor perfect for situations requiring precise control and powerful output.



With its strong starting torque (1809.4 mN·m for the 12V version and 3839.525 mN·m for the 24V version) and high starting current, the YGA37BL3626 epicyclic gear motor can provide additional power during startup, ensuring smooth startup under high load. Additionally, this motor is widely used in driving robot joints, such as the shoulder, elbow, and wrist, providing precise motion control and strong support for robots, and is widely applied in industrial automation, medical robots, and service robots. Whether for high-precision motion control or stable driving under high loads, the VSD epicyclic gear motor ensures exceptional power and performance to meet customers' diverse needs.



YGA37BL3626 Gear Motor Design

YGA37BL3626 Gear Motor Performance



YGA36BL3657 Epicyclic Gear Motor

VSD's YGA36BL3657 epicyclic gear motor is a high-performance motor combining high torque and high efficiency, specifically designed for applications requiring precise control and high-load output. Available in both 12V and 24V versions, the 12V version delivers a maximum torque of 317.348 mN·m at the maximum power speed of 316 r/min, while the 24V version reaches a maximum power speed of 418 r/min, with a maximum power torque of 371.926 mN·m. With its outstanding performance, the YGA36BL3657 epicyclic gear motor is perfect for high-load and high-precision control applications.



In addition, the wear resistance and low starting current of this epicyclic gear motor ensure efficient operation even after prolonged use. Its starting torque reaches 1661.302 mN·m (for the 12V version) and 2153.935 mN·m (for the 24V version), with a relatively low starting current, ensuring smooth operation when starting the vehicle. Its main application areas include robotic gripping systems and telescopic arms, providing strong and stable driving force for industrial robots and automation equipment. Whether for high-load operation or fine control needs, the VSD epicyclic gear motor offers excellent support for your system.



YGA36BL3657 Gear Motor Design

YGA36BL3657 Gear Motor Performance



YGA36BL3640 Epicyclic Gear Motor

VSD's YGA36BL3640 epicyclic gear motor is a highly efficient motor designed for high-load and precise control, widely used in systems requiring powerful output and precision operation. Available in both 12V and 24V versions, the 12V version provides a maximum power torque of 1643.044 mN·m, while the 24V version can output up to 2861.74 mN·m of strong torque at maximum power. Whether for lifting platforms or balancing and stabilization systems, this epicyclic gear motor can provide reliable power support to ensure stable system operation.



In addition to high torque output, the YGA36BL3640 epicyclic gear motor also features strong customizability, allowing customers to tailor parameters such as reduction ratio and voltage for specific applications to meet personalized power needs. Furthermore, the motor supports servo control, enabling precise motion control in dynamic environments and adapting to various complex working conditions. With its outstanding starting torque (7455.6 mN·m for the 12V version and 18372.233 mN·m for the 24V version), the YGA36BL3640 epicyclic gear motor is suitable for high-load startup and ensures smoothness and stability during startup.



YGA36BL3640 Gear Motor Design

YGA36BL3640 Gear Motor Performance



YGA25BL-2430 Epicyclic Gear Motor

VSD's YGA25BL-2430 epicyclic gear motor is a high-performance motor specifically designed for high-precision control and high-load applications. It is available in 12V and 24V versions, with the 12V version providing a maximum power torque of 458.99 mN·m, while the 24V version offers a torque of 638.77 mN·m. Whether for conveyor belt drives or automatic assembly systems, this motor provides stable, reliable power output, ensuring smooth operation in various working environments.



In addition, the YGA25BL-2430 epicyclic gear motor features precise control, high-temperature resistance, and strong compatibility, meeting the demanding requirements of different industrial applications. Its starting torque is 1514.49 mN·m (for the 12V version) and 2432.88 mN·m (for the 24V version), with a low starting current, ensuring smooth startup of the equipment. At the same time, due to its precise control capability and high-temperature resistance, the YGA25BL-2430 epicyclic gear motor is particularly suitable for use in high-temperature, complex environments. Its high compatibility allows it to be widely applied in automation production lines, helping industrial equipment operate efficiently.



YGA25BL-2430 Gear Motor Design

YGA25BL-2430 Gear Motor Performance



YGA25BL-2418 Epicyclic Gear Motor

VSD's YGA25BL-2418 epicyclic gear motor is a motor specifically designed for high-load and high-efficiency applications, capable of providing powerful torque output to ensure stable operation under complex working conditions. This motor is available in 12V and 24V versions, with the 12V version providing a maximum power torque of 483.08 mN·m, while the 24V version offers a strong torque of up to 845.72 mN·m. Its maximum power output is 0.63W (for the 12V version) and 2.71W (for the 24V version), and during startup, it provides starting torque of up to 1560.88 mN·m (for the 12V version) and 3514.16 mN·m (for the 24V version), ensuring stable operation under high load conditions.



The epicyclic gear motor is widely used in automatic packaging machines, labeling machines, and other automation production equipment, thanks to its overload resistance and high torque characteristics. With its low starting current and high-load capability, the YGA25BL-2418 can effectively handle frequent start-stop cycles and long-term operation, making it the ideal choice for precision control and efficient operation. Its robust design ensures excellent performance in high-load and harsh working environments, suitable for power transmission needs in various industrial automation equipment.



YGA25BL-2418 Gear Motor Design

YGA25BL-2418 Gear Motor Performance



VSD-G370 Epicyclic Gear Motor

The VSD-G370 epicyclic gear motor offers high efficiency and high cost-effectiveness, making it the ideal driving solution for various automation equipment. This motor has a rated voltage of 24V, with an unloaded speed of 3489 r/min, providing excellent power output. At maximum power, the speed is 2896 r/min, and the maximum power torque is 2.38 mN·m, with a maximum power of 0.722W, showcasing its stability and excellent performance during long-term operation. Additionally, this motor is high-temperature resistant, making it suitable for various high-temperature working environments, ensuring efficient operation over extended periods.



The VSD-G370 epicyclic gear motor is widely used in sorting systems, packaging machines, and CNC machines in automation equipment. Its low starting current (0.238 A) and relatively high starting torque (13.999 mN·m) allow it to withstand significant loads and quickly start up the vehicle, ensuring efficient system operation. With its excellent cost-effectiveness and high reliability, the VSD-G370 is an indispensable power component in various fields of industrial automation.



VSD-G370 Gear Motor Design

VSD-G370 Gear Motor Performance





The VSD epicyclic gear motor, with its exquisite technology and excellent performance, has become a widely applied driving system solution in the industry.



Efficient Power Transmission

The VSD epicyclic gear motor adopts a unique epicyclic gear structure, including the sun gear, planet gears, and gear ring, ensuring efficient power transmission and low energy loss. This design effectively converts the input power into output torque, providing stable operating performance, and is widely used in scenarios that require precise control and high load.



Outstanding Wear Resistance

The VSD epicyclic gear motor uses all-steel gears, a high-strength material that greatly enhances the gear's wear resistance, allowing it to maintain high work efficiency even in high torque and long-duration operating environments.



Powerful Overload Capacity

The unique structure of the epicyclic gear system gives the VSD epicyclic gear motor powerful overload resistance. By effectively distributing the load, the motor can withstand pressures exceeding the rated load for short periods without damage.



Low Starting Current

Compared to traditional motors, the VSD epicyclic gear motor has a lower starting current, reducing the impact on the power supply system and extending the motor and system's lifespan. This low starting current characteristic makes the motor suitable for a wide range of applications.



Customizable Service

The VSD epicyclic gear motor offers comprehensive customization options. Customers can tailor the gear material, structure, reduction ratio, voltage, bearings, dimensions, etc., according to specific needs. This customization capability ensures the motor can perfectly adapt to various complex applications, meeting different working environments and performance requirements.



Excellent Protection Capabilities

The VSD epicyclic gear motor supports IP65 and IP67 protection ratings, effectively protecting against dust, water, and corrosion, adapting to harsh working environments. Whether in high-temperature, high-humidity, dusty, or chemically corrosive environments, the VSD epicyclic gear motor maintains stable performance, ensuring the long-term reliable operation of equipment.



These features make the VSD epicyclic gear motor an ideal driving solution in many fields, whether in industrial automation, robot drives, or high-load mechanical transmission, providing excellent performance and stability.





The VSD epicyclic gear motor, with its excellent power transmission efficiency, durability, and customization features, is widely used in multiple industries, especially in applications that require high torque, high precision, and high load capacity. Whether in the robotics field or the industrial equipment field, the VSD epicyclic gear motor can provide stable, reliable power support.



Robotics Field

In robotic applications, the VSD epicyclic gear motor is widely used to drive wheeled or tracked systems, providing smooth movement and precise control. It can undertake joint drive tasks, providing the robot with precise motion control, ensuring coordinated operation between joints. In addition, the epicyclic gear motor is also widely used in gripping devices, providing strong torque for the robotic arm, ensuring a secure grip on objects.



In the steering system of mobile platforms, the VSD epicyclic gear motor also performs excellently, with its strong load-bearing capacity and low starting current, providing stable power output in various steering applications. The reduction section in the transmission system effectively reduces the speed through the epicyclic gear structure, increasing the torque output and ensuring the efficient operation of mechanical equipment.



For balancing systems and elevating platforms or telescopic arms that require precise balance and stability, the VSD epicyclic gear motor provides stable driving power, ensuring system stability and reliability. In collaborative robots, the VSD epicyclic gear motor can also provide stable power output, ensuring efficient operation when robots cooperate with each other.



Industrial Equipment Field

In the industrial equipment field, the VSD epicyclic gear motor is one of the core components of automated production line drive systems. Whether it is for conveyor belt drives, rotating devices, automatic assembly systems, or automated handling equipment, the epicyclic gear motor provides efficient and stable power support, ensuring smooth operation of the production line.



In packaging equipment, the VSD epicyclic gear motor is commonly used in automatic packaging machines, labeling machines, sorting systems, and packing machines. With its strong torque output and precise control ability, it ensures precise operation of each step in the packaging process, improving production efficiency.



In the CNC (Computer Numerical Control) field, the VSD epicyclic gear motor plays a critical role in spindle drives, cutting head adjustments, worktable adjustments, and tool changes. Its high torque and low starting current characteristics make these precise operations smoother and more accurate, meeting high-precision machining requirements.





Since its establishment in 2011, VSD has been dedicated to providing high-quality planetary gear motor solutions. As a professional planetary gear motor manufacturer, we have obtained ISO, CE, and other international certifications, and are equipped with advanced testing equipment to ensure that each product meets strict quality standards. Our products cover a variety of specifications and functions, capable of meeting the needs of various customers, whether in industrial automation, robotic applications, or high-load drive systems. With years of industry experience and technical accumulation, we provide customers with cost-effective planetary gear motors and can offer OEM/ODM customization based on customer requirements to help meet individualized needs.



VSD has an independent R&D team, continuously investing significant resources each year in motor development and new design to ensure that our planetary gear motors remain at the forefront of technology. Our factory is equipped with comprehensive production facilities, and customers can visit the factory either online or offline to ensure that the production process is transparent and reliable. We also offer several product tests, including hardness tests, comprehensive performance tests, magnetic field distribution tests, and leakage tests, to ensure that the performance and quality of each planetary gear motor are in optimal condition.



Regarding pricing, we offer competitive prices, while providing free samples for customers. The sample costs can be deducted after an order is placed. Additionally, we support multiple shipping methods and provide complete customs clearance services, ensuring that the products are delivered smoothly and safely worldwide.



By choosing VSD, you not only receive high-quality planetary gear motors, but also enjoy customized solutions, reasonable prices, and comprehensive after-sales services. Let us become your reliable planetary gear motor supplier, helping your business reach new heights.
