DC 12V Planetary Gear Motor
Diameter: 22mm,
Length: 32mm,
Axial Clearance: 0.05-0.5mm
The high-torque electric mini reduction planetary gear motor adopts high-quality metal gears to avoid broken teeth, greatly improve the service life, high temperature resistance, wear resistance, strong bearing capacity, strong and durable, and effectively protect the gearbox motor body.
Description
Overview
Warranty | 3 months - 1 year |
Place of Origin | Guangdong, China |
Brand Name | Vshida |
Model Number | GBP22-180SH |
Usage | Robot, semiconductor equipment, medical equipment, automatic control system, vehicle, model aircraft, automation industry, communication equipment, etc. |
Type | Gearbox motor |
Weight | TBD (different ratio different weight) |
Components | Diversifed |
Construction | Permanent Magnet |
Commutation | Brushless |
| Standard or non-standard | Non-standard |
Protect Feature | Customized |
Starting torque | 6.235 mN.m |
Rated speed | 4000±5% (rpm) |
Rated Voltage | 12 (V) |
Rated Current | 0.025 (A) |
Payment terms | 30% advance, 70% balance |
Certificate | ROHS |
Customizated | Acceped |
Company Highlights
Supply Ability
Supply Ability: 4500000 Piece/Pieces per Month dc motor with counterweight
Packaging & Delivery
Packaging Details
Micro motor packing: Carton Box Our standard shipping mark for each model is as below Q'ty: pcs N.W.: kgs G.W.: kgs Meas.: L*H*W cm Your own shipping instruction is welcome.
Port: Shenzhen / HongKong
Product Description
An average of two months to develop a new motor.
Product Parameter
VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STARTING | |||||
NOMINAL V | SPEED r/min | CURRENT A | SPEED r/min | CURRENT A | TORQUE mN.m | OUTPUT W | TORQUE mN.m | CURRENT A |
12 | 4400 | 0.025 | 3464 | 0.093 | 1.326 | 0.481 | 6.235 | 0.343 |
Motor outline
Motor Curve
The above specifications are for reference only, the specific dc planetary gear motor model and parameters can be customized.
Product Features
The planetary gear motor has compact structure, small volume, low vibration, high efficiency, stable operation, high starting torque, easy control, and low price，high precision, and complete reduction ratios (16, 62, 84, 104, 231, 316, 370, 455, 1014)
Product Details
| 100% actual photos |
|
End cap: There are two brush feet at the bottom, which is more convenient to complete various welding processes and more convenient for wiring. | Bearings: The center shaft is CNC machined, which increases the friction force, makes the transmission more stable, and is easy to connect and fix (the bearing can be customized) | |
| 100% actual photos |
|
The motor coil is made of pure copper, with low resistivity, better electrical conductivity, high strength, low power consumption, low calorific value and higher output efficiency. | Chassis: The motor is made of high-quality aluminum, which has the characteristics of corrosion resistance, not easy to rust, and reliable performance. |
Our Advantage
1. Space saving, reliable and durable, strong overload capacity (reduction ratio can be customized according to different application fields)
2. Low power consumption, superior performance, and the efficiency of the reducer is as high as 95%.
3. Low vibration, low noise, high energy saving, high-quality steel, rigid cast iron box, and high-frequency heat treatment of gear surfaces.
4. After precision machining, the positioning accuracy is ensured, the electromechanical integration is formed, and the quality characteristics of the product are fully guaranteed.
5. Prompt delivery, strong production and R&D capabilities, high quality and reasonable price, perfect service system, customized design.
Company Strength
Product Certificate
Some of our partners
Application
Transport Packing
If you have special packing needs, please contact us in advance.
Buying Guides
Payment & Delivery
FAQ
1. How to choose a suitable motor?
If you have motor pictures, drawings, or detailed specifications such as voltage, speed, torque, motor size, motor working mode, required life and noise level, please tell us, we can recommend a suitable motor according to your requirements or give you Customize the motor to suit your requirements.
2. Do you have custom service for your standard motors?
We can customize to your requirements for voltage, speed, torque and shaft size/shape. If you need to solder extra wires/cables to the terminals or need to add connectors, capacitors or EMC, we can also provide that for you.
3. Do you have a separate motor design service?
Yes, we are a real manufacturer with an independent R&D team that can design motors individually for customers.
4. Can I have a sample for testing first?
This is absolutely fine. After confirming the required motor specifications and outline drawings, we will arrange proofing, and send the samples to you for testing after passing the test.
5. How do you ensure the quality of the motor?
We have our own inspection procedures: for incoming materials, we sign samples and drawings to ensure that the incoming materials are qualified; for the production process, we conduct patrol inspections and final inspections during the process to ensure that the products are qualified before shipping.
