37MM High Quality Brushless Fan Motor DC 12v

The VBL-3725 brushless DC motor uses electronic reversing rather than mechanical steering. Compared with the brush DC motor, the working life is long and eliminates the noise, spark and electromagnetic interference of mechanical steering. The performance of the control motor has great convenience and reasoning. It can be mainly divided into two parts: motor control and circuit control. The motor consists of rotor whose main component is permanent magnet and stator of silicon steel plate and copper wire.37MM High Quality Brushless Fan Motor DC 12v This single-speed brushless fan motor is designed as an upgrade to your electric fan assembly and currently uses a brush motor for your condenser, oil cooler or radiator cooling system.

The advantage of using a brushless motor is that there is no surge current at each start. In fact, the motor has a soft start feature, so every time it starts, it doesn't jump straight to its full speed, but it gradually accelerates to its maximum speed. Please carefully check the dimensional drawings. You may need to make some spacers to the right height so that this motor fits your fan assembly. Also make sure that the motor you intend to replace is based on clockwise rotation. Since this is a brushless DC motor, please note your polar connection. The red line is the positive electrode 12v DC electrode connected to your power supply, and the black line is the negative extreme connected to your power supply. Reverse polarity can damage the electronic controller of the motor.

Product Description

Model	VBL-3725
Size	Dia37.5*L24mm
Shaft Dia	3mm
Certification	ISO9001,IATF16949
Weight	~80gram
Endplay	0.5mm max
Lifetime	30000h
Phase	3
Rotation	CW/CCW
Insulation and pressure resistance	100 Vac voltage is applied between the lead and the housing, 1 second and leakage current 5 mA
Insulation resistance	A 500 Vdc voltage is applied between the lead line and the housing, and the insulation resistance is 50 MQ
Rated voltage	5V
No Load	300mA max,4000±10% rpm
Insulation grade	Class B
On Load	800mA max,3300±10% rpm
Other performance available

Brushless Direct Current Motor is a type of energy-saved motor. High efficiency and energy saving is an important difficulty in fan motor manufacturing. On the one hand, it is necessary to provide higher speed, greater air volume and more stable performance through reasonable design and innovative technology. At the same time, it is necessary to ensure the power consumption as little as possible and reduce energy consumption to contribute to environmental protection. Noise and vibration are the difficulties in fan motor manufacturing.

Noise and vibration not only affect the use experience, but also have adverse effects on physical health. Therefore, new materials and technologies need to be adopted in the manufacturing process, optimize the structural design, reduce problems such as wear and noise and vibration, and provide a more comfortable and quiet use experience. Reliability and durability are also one of the manufacturing difficulties in fan motor manufacturing. Especially in the high temperature, humidity and dust environment, the working load of the motor will increase, prone to failure or premature damage. Therefore, manufacturers need to invest more energy and research funds to improve the motor performance.

High Light some characteristics of the 37MM High Quality Brushless Fan Motor DC 12v

1.High efficiency

In general, the efficiency of single-phase AC motor is under 30% , but the efficiency of single-phase DC motor is above 40%.

2.Easy control the speed

Using PWM to control the speed and obtain linear deviation.

3.Soft start-up ( Lower start-up current)

Decreasing the start-up current to reduce the damage for matching system.

4.High reliability and long life

Using high tech bearing system to ensure high reliability and long life.

5.Wide temperature range

Operation temperature : -10~+80°C(5~95% RH),
Storage temperature: -40~+85°C(5~95% RH)

6.Speed feedback and alarm function

System can easy read real time revolution and give alarm signal when rotor stops.



Company Profile

Weishida Is a professional micromotor manufacturer in Shenzhen, China. Has been a reliable motor solutions manufacturer since 2011. Our mature motor technology, application expertise and complete customization platform make Weishida Motor an ideal partner for customized product development projects. Weishida Electric Motors is committed to providing our customers with superior differentiated products and supply chain success. For those designers who require performance leadership and supply assurance, the Weishida motor is a reliable choice. We serve many industries, including smart home and home appliances, automobiles, healthcare, smart agriculture, industrial automation, and power tools.

1. DC Sine wave vector control

2. Control the positive-negative rotating of motor

3. Protective functions

Over-voltage & under-voltage protection

Over-temperature protection

Locking protection

Constant power protection

Dimming & Color control

Using mobile phone(APP) as the remote(in the same wifi)

Timing function

Flexible

All of our products are made based on different requirements by choossing suitable materials and design. Except the product itself, we also provide OEM service and related accessories for your convenience.

Professional

40+ engineers with more than 20 years experience in motor industry. We provide our clients professional service and high quality products.

Swift

We ensure your inquiry and query before and after sales can be handled within 24 hours except the weekends and holidays.

Factory

450+ Experienced staff

Workshop

Clean and tidy production lines

Warehouse

Manage the warehouse based on FIFO

Team

40+ experienced engineer and 10+ professional sales

Package

The fan motor available for wholesale;

The place of origin is in China,when you buy one or two,please consider freight(by air or by sea) into the cost;

Accept bulk order with Container delivery;

Please contact us online (click here) Or send inquiry message to our email: sales@vsdmotor.com

Payment

We only provide samples to our customers and can meet our MOQ for further ordering after sample approval. Some people are free, while others are not. Freight charges will be paid by the buyer.
The delivery time of samples is usually about 15-20 working days, and some popular models are about 15 days.

FAQ

Can I get a spec before 37MM High Quality Brushless Fan Motor DC 12v sample arrangement?

For all of our motors, we customerize them based on different requirements. We don't make standard ones and put then in warehouse then sell to clients. Spec is available after sample making. Sometimes if we arranged similar ones before, we can provide for reference. For others, we can only provide the outline.
