High Speed DC 12V Brushless Motor

High Speed DC 12V Brushless Motor has a diameter of 42mm, works normally under DC 12V, 24V, 36v, output power is 10-40W (customizable), voltage is 12V, no-load current is 0.3A, starting current is 12A, no-load speed is 5000 rpm . The voltage is 24V, the no-load current is 0.278A, the starting current is 11.477A, and the no-load speed is 8000 rpm. The motor is a small-volume, high-speed, power-type brushless inner-rotor motor with built-in drive. It adopts a rare-earth medium-strong magnetic rotor and a 9-pole stator coil. Mainly used in household appliances, medical equipment, electric tools, commercial equipment, water pumps, air pumps, fans, coffee machines, centrifuges, electric drills, printers, copiers, etc.; provide supporting drivers, encoders, gear boxes, etc., welcome to inquire.

Company Highlights

Overview

Warranty	3months-1year
Place of Origin	Shenzhen, China
Brand Name	Vshida
Model	VBL-4260
Usage	Household appliances, medical equipment, electric tools, commercial equipment, water pumps, air pumps, fans, coffee machines, centrifuges, electric drills, printers, copiers, etc.
Type	Micro BLDC Motor
Weight	TBD (different ratio different weight)
Components	Diversifed
Construction	Permanent Magnet
Commutation	Brushless
Protect Feature	Customized(Waterproof, Fireproof)
Efficiency	82%
Rated Voltage	24 V
No Load Speed	7198 rpm
Load Speed	6229
No Load Current	0.27
Starting Torque	350 mN.m
Product Name	BLDC Motor
Power	10-40 W
Direction of Rotation	CW&CCW
Payment terms	30% advance, 70% balance
Critificate	IATF16949
Customized	Acceped

Product Description

The company has independent R&D personnel who can adjust the design according to your needs. It has strong research and development capabilities, and produces new motors every month on average.



Product Parameter

VOLTAGE		NO LOAD		AT MAXIMUM EFFICIENCY				STARTING
OPERATING RANGE	NOMINAL V	SPEED r/min	CURRENT A	SPEED r/min	CURRENT A	TORQUE mN.m	OUTPUT W	TORQUE mN.m	CURRENT A
8-16	12	4273	0.302	3557	1.499	37.20	13.861	222.21	7.455
18-26	24	7062	0.245	6114	1.579	51.01	32.657	379.81	10.180

Motor Outline

Performance Curve

The aforementioned motor specifications can be modified and tailored to suit the needs of the customer. Please get in touch with us to get samples for testing if you have any particular requirements.

Product Details

	100% actual photos
It is wound on a high-quality iron core with excellent temperature resistance by pure copper wire. Uses less energy and has lower current resistance.		Increase friction, enhance transmission stability, and facilitate connection and fastening, the bearings are made using CNC machining.
	100% actual photos
A fixed electronic rotor with higher heat dissipation, greater matching, and a longer lifespan is constructed from quality raw materials.		High-quality raw materials with high hardness, temperature resistance, low corrosion, low wear, and low rust are used to create the motor casing.

Motor Description

1. Ball bearings are used, with small friction, firm oil seal, high load-carrying capacity, ultra-smooth drive, almost no noise, safe use and stable performance.
2. The stator winding of the motor is made of copper wire, low heat generation, low loss, long life, clockwise or counterclockwise; reverse rotation is supported;
3. Speed regulation function: an external DC speed controller is required, and the High Speed DC 12V Brushless Motor can realize the speed regulation function
4. Perfect after-sales service system, guarantee free replacement of defective products, ensure worry-free after-sales, and provide technical support for customers;
5. Wiring mode: red: "+"; black: "-"; yellow: FG signal output (for external equipment to detect the motor speed, two pairs of polar magnetic ring motors output 6 square wave pulses per revolution); white: motor positive Reverse control; blue: speed regulation (speed is proportional to voltage)

Company Strength

The Vshida Micro Motor Company uses state-of-the-art tools for production, research, and development in addition to cutting-edge production management strategies. has accreditation for both the ISO 9001:2015 and IATF 16949:2016 quality management standards. The company's current manufacturing facility, with a floor area of more than 10,000 square meters, more than 500 employees, more than 300 sets of automation equipment, more than 40 assembly lines, 30 R&D personnel, and a daily output of approximately 200,000 motors, is equipped to handle both large orders and specific customer requests.

​

To provide high-quality assurance for your products, all motors have completed a range of reliability testing, including noise tests, waterproof tests, life tests, impact tests, storage tests, salt spray tests, etc. The company has automatic manufacturing tools such automatic winding machines, automatic stator machines, automatic soldering machines, and other high-tech machinery, which increases production efficiency.

​

Product Certificate

It has so far passed several international certifications and patent certifications in order to fulfill the needs of clients for different certificates.​

Partners

​

We are excited to work with you as a reliable partner in China. We have been devoted to micro motor research and development for a very long time, supplying the vast majority of our customers in Europe and America while also keeping up with the enormous demand.

Why Choose Us

Motor Application

Micro motors are incredibly flexible and can be designed for a wide range of application scenarios.

Contact us if you have any specific requirements.

​

Transport Packing

​

The right size cartons with shock-absorbing foam inside.

If you require any special packing services, do get in touch with us in advance.

Payment & Delivery

​

Method of Controlling Noise and Vibration of High Speed DC 12V Brushless Motor

1.Bearing selection
If the bearing system in a BLDC motor is properly designed, it can last over 25,000 hours. By paying due attention to the bearing design when using high-quality ball bearings, it is possible to reduce the load intensity on the bearing by more than 100 times, thereby optimizing performance and extending life.

2.Magnetic material
Optimizing the internal balance of brushless motors can be enhanced by using specialized magnetic materials in the rotor that provide higher energy density within a smaller form factor. The use of NdFeB material means that the rotor assembly can be smaller and provides optimum internal balance for minimum vibration. Neodymium magnets also do not demagnetize over time, so they provide more consistent performance over a longer period of time than other materials.

3.Machined parts
One of the key factors in reducing vibration is improving the precision of the motor's internal components. Where typical motors are designed using stamped parts, high-precision brushless DC motors contain machined parts. Motors are tested prior to delivery to ensure parts are installed correctly for optimal operation.
